OpenTestSystem.Otx.Core.Actions.Assignment Class Reference

Assigns a value to a variable. More...

Inheritance diagram for OpenTestSystem.Otx.Core.Actions.Assignment:

Public Attributes
Variable	result
	Cardinality [1] Describes the variable to which the resulting value of term evaluation will be assigned. More...
Term	term
	Cardinality [1] Describes the value which shall be evaluated out of the given term at runtime. More...
Public Attributes inherited from OpenTestSystem.Otx.Core.Actions.ActionRealisation
OtxLink	validFor
	Cardinality [0..1] Validity of ActionRealisation. More...

Detailed Description

Assigns a value to a variable.

The ActionRealisation assigns a right-value (Term) to a left-value (Result).

Syntax

Variable result = Term term;

Example

// Local Declarations

Integer Variable1;
String Variable2;
Float Variable3;

// Flow

Variable1 = 123;
Variable2 = "Hello";
Variable3 = 0.123;
Variable3 = Variable1;

Checker rules

CheckerRule.Core_Chk023 - Type-safe assignments
Extensions.TestResultHandling.CheckerRule.TestResultHandling_Chk302 – correct hierarchy of TestResultContainer

Member Data Documentation

result

Variable OpenTestSystem.Otx.Core.Actions.Assignment.result

Cardinality [1]
Describes the variable to which the resulting value of term evaluation will be assigned.

term

Term OpenTestSystem.Otx.Core.Actions.Assignment.term

Cardinality [1]
Describes the value which shall be evaluated out of the given term at runtime.
