A constructor for QuantityInterval More...

Inheritance diagram for OpenTestSystem.Otx.Extensions.Range.Terms.CreateQuantityInterval:

Public Attributes
StringTerm	label
	Optionally represents the label to categorize the interval. More...

QuantityTerm	lowerLimit
	Optionally represents the lower limit of the interval. If the lower limit is omitted, the lower limit value is -Infinity. More...

IntervalSemanticTerm	semantic
	Optionally represents the semantics of how values inside the interval are interpreted. If the type is omitted, the semantic is NONE. More...

QuantityTerm	upperLimit
	Optionally represents the upper limit of the interval. If the upper limit is omitted, the upper limit value is Infinity. More...

Public Attributes inherited from OpenTestSystem.Otx.Core.Terms.Term
MetaData	metaData
	Cardinality [0..1] The `MetaData` type allows tools to store additional, mainly tool-specific data. More...

Detailed Description

A constructor for QuantityInterval

CreateQuantityInterval is a QuantityIntervalTerm. It is a constructor for QuantityInterval.

Exceptions

Quantities.Exceptions.InvalidConversionException If the physical dimension of the lower limit does not match the physical dimensions inside the upper limit.

Checker rules: CheckerRule.Range_Chk002 – Identical physical dimensions

Syntax: QuantityIntervalTerm = Range.CreateQuantityInterval(QuantityTerm lowerLimit, QuantityTerm upperLimit, IntervalSemanticTerm semantic, StringTerm label);

Examples: // Local Declarations

Range.QuantityInterval QuantityInterval1;

// Flow

QuantityInterval1 = Range.CreateQuantityInterval(5.0 [@Unit, "km"], 100.0 [@Unit, "km"], @IntervalSemantic:SUCCESS, "Label1");

Member Data Documentation

◆ label

StringTerm OpenTestSystem.Otx.Extensions.Range.Terms.CreateQuantityInterval.label

Optionally represents the label to categorize the interval.

◆ lowerLimit

QuantityTerm OpenTestSystem.Otx.Extensions.Range.Terms.CreateQuantityInterval.lowerLimit

Optionally represents the lower limit of the interval. If the lower limit is omitted, the lower limit value is -Infinity.

◆ semantic

IntervalSemanticTerm OpenTestSystem.Otx.Extensions.Range.Terms.CreateQuantityInterval.semantic

Optionally represents the semantics of how values inside the interval are interpreted. If the type is omitted, the semantic is NONE.

◆ upperLimit

QuantityTerm OpenTestSystem.Otx.Extensions.Range.Terms.CreateQuantityInterval.upperLimit
