Creates an XmlDocument from an XMLElementTerm. More...

Inheritance diagram for OpenTestSystem.Otx.Extensions.XML.Terms.CreateXmlDocument:

Public Attributes
EncodingTerm	encoding
	Cardinality [0..1] Optional encoding of the XML document (Default = "UTF-8"). If an invalid encoding (BIN, OCT, HEX) is specified, an XmlFormatException shall be thrown. More...

XmlElementTerm	rootNode
	Cardinality [1] Assignment of a root node term, which will be included in the document. More...

BooleanTerm	standalone
	Cardinality [0..1] The optional standalone attribute of an XML declaration (Default = "false"). More...

StringTerm	version
	Cardinality [0..1] Optional XML version (Default = "1.0"). More...

Public Attributes inherited from OpenTestSystem.Otx.Core.Terms.Term
MetaData	metaData
	Cardinality [0..1] The `MetaData` type allows tools to store additional, mainly tool-specific data. More...

Detailed Description

Creates an XmlDocument from an XMLElementTerm.

The CreateXmlDocument activity creates an XmlDocument from an XMLElementTerm.

Exceptions

Exceptions.XmlFormatException	If the given encoding is invalid.
Exceptions.XmlChangeException	If the <rootNode> element has already been added to a parent or it is used as a root node of another document.

Syntax: XmlDocumentTerm = Xml.CreateXmlDocument(XmlElementTerm rootNode, StringTerm version = "1.0", EncodingTerm encoding = @Encoding:UTF-8, BooleanTerm standalone = false);

Examples: // Local Declarations

Xml.XmlElement XmlElement1;

Xml.XmlDocument XmlDocument1;

// Flow

XmlElement1 = Xml.CreateXmlElement("root");

XmlDocument1 = Xml.CreateXmlDocument(XmlElement1, "1.0", @Encoding:UTF-8, false);

Member Data Documentation

◆ encoding

EncodingTerm OpenTestSystem.Otx.Extensions.XML.Terms.CreateXmlDocument.encoding

Cardinality [0..1]
Optional encoding of the XML document (Default = "UTF-8"). If an invalid encoding (BIN, OCT, HEX) is specified, an XmlFormatException shall be thrown.

◆ rootNode

XmlElementTerm OpenTestSystem.Otx.Extensions.XML.Terms.CreateXmlDocument.rootNode

Cardinality [1]
Assignment of a root node term, which will be included in the document.

◆ standalone

BooleanTerm OpenTestSystem.Otx.Extensions.XML.Terms.CreateXmlDocument.standalone

Cardinality [0..1]
The optional standalone attribute of an XML declaration (Default = "false").

◆ version

StringTerm OpenTestSystem.Otx.Extensions.XML.Terms.CreateXmlDocument.version
